Explosion-proof design
Version that allows to use the equipment in hazardous areas
Serves for air compression, uses screw oil-filled or oil-free compressor
Serves as a "buffer" of compressed air to equalize the pressure at the inlet to the compressor adsorption columns
Serves to equalize pressure surges and partial accumulation
Serves to remove moisture from compressed air to the dew point of +40 °F
To remove micro-particles of oil, dust and other contaminants from compressed air
Serves for separation of prepared compressed air into its main components - nitrogen and oxygen
01
Explosion-proof design
Version that allows to use the equipment in hazardous areas
02
Booster compressor
Serves to raise the pressure of the production gas
03
Filling station
Equipment complex allowing to fill standard cylinders with compressed gas at a pressure of up to 5000 psig
04
Aftertreatment system
Enables production oxygen or higher nitrogen concentrations
Size, LxWxH, mm: 31 × 31 × 51 in
Weight, kg: 600
Capacity, SCFH
Air required, SCFM
4,3
9,7
3,1
8,6
2,5
7,8
2,2
7,5
1,9
8,6
1,2
7,8
Size, LxWxH, mm: 31 × 31 × 66
Weight, kg: 800
Capacity, SCFH
Air required, SCFM
8,1
18
6,2
16
5,0
15
3,7
12
3,1
14
1,9
11
Size, LxWxH, mm: 39 × 28 × 75
Weight, kg: 1050
Capacity, SCFH
Air required, SCFM
12,4
27
9,3
24
6,2
19
5,6
18
5,0
22
3,1
19
Size, LxWxH, mm: 39 × 28 × 67
Weight, kg: 860
Capacity, SCFH
Air required, SCFM
15,5
34
12,4
31
9,3
29
6,8
22
6,2
28
5,0
30
Size, LxWxH, mm: 39 × 31 × 71
Weight, kg: 940
Capacity, SCFH
Air required, SCFM
18,6
41
15,5
39
10,6
33
8,7
28
7,5
34
5,6
34
Size, LxWxH, mm: 43 × 28 × 79
Weight, kg: 1100
Capacity, SCFH
Air required, SCFM
22
48
19
47
12,4
38
9,9
32
9,3
42
6,2
37
Size, LxWxH, mm: 47 × 33 × 80
Weight, kg: 1500
Capacity, SCFH
Air required, SCFM
31
68
25
62
19
58
14
44
12,4
56
8,1
49
Size, LxWxH, mm: 51 × 35 × 81
Weight, kg: 1880
Capacity, SCFH
Air required, SCFM
37
82
31
78
22
68
17
53
16
70
9,3
56
Size, LxWxH, mm: 59 × 35 × 83
Weight, kg: 2315
Capacity, SCFH
Air required, SCFM
50
109
37
93
25
77
20
63
19
84
12
75
Size, LxWxH, mm: 63 × 35 × 79
Weight, kg: 2750
Capacity, SCFH
Air required, SCFM
62
137
50
124
37
116
28
89
25
112
19
112
Size, LxWxH, mm: 67 × 35 × 83
Weight, kg: 3200
Capacity, SCFH
Air required, SCFM
75
164
62
156
43
135
34
109
31
140
22
131
Size, LxWxH, mm: 67 × 39 × 85
Weight, kg: 3750
Capacity, SCFH
Air required, SCFM
93
205
75
187
50
154
40
128
37
168
25
149
Size, LxWxH, mm: 71 × 43 × 91
Weight, kg: 4630
Capacity, SCFH
Air required, SCFM
124
274
93
233
62
193
56
178
50
224
31
187
Size, LxWxH, mm: 75 × 47 × 102
Weight, kg: 5500
Capacity, SCFH
Air required, SCFM
155
342
124
311
87
270
68
217
62
280
43
261
Size, LxWxH, mm: 79 × 49 × 106
Weight, kg: 6400
Capacity, SCFH
Air required, SCFM
186
411
155
389
106
328
81
256
75
336
53
317
1. Choose the right nitrogen concentration
Improperly chosen concentrations can be a factor in significantly increasing the price several times over. A 0.05% difference in concentration can double the cost of a system.
2. Calculate the capacity of the station
Considering all the parameters of the consumers, calculate the total amount of nitrogen consumed. Pay attention to the units of measurement, the flow should be given to normal conditions, ft³/h at 15 psig and 68℉.
3. Take into account the operating conditions
All station parameters are given under standard operating conditions of 68℉, higher temperatures above 95℉ have a negative effect on the performance of the station.
4. Choose a compressor with a 10% margin
Many factors must be taken into account for the correct operation of the system: the nature of consumption, the number of peak loads, additional losses of compressed air, the volume of air receivers and much more.
We do not share your personal information with third parties. By clicking the button, you give consent to the processing of personal information.
Supplied equipment: PSA Nitrogen system GB-1500
Concentration: 97%
Capacity: 55000 m3/h
Supplied equipment: Nitrogen station
Concentration: 99.9995%
Capacity: 13420 m3/h
Supplied equipment: Hydrogen station
Concentration: 99.999%
Capacity: 600 m3/h
Supplied equipment: Nitrogen generator GN-120
Concentration: 99.995%
Capacity: 1715 m3/h
Supplied equipment: Nitrogen generator GN-20
Concentration: 99.99%
Capacity: 380 m3/h
Supplied equipment: Nitrogen generator GN-15
Concentration: 99.95%
Capacity: 385 m3/h
Supplied equipment: Nitrogen generator GN-23
Concentration: 99.99%
Capacity: 700 m3/h
Supplied equipment: Nitrogen generator GN-15
Concentration: 99,5%
Capacity: 590 m3/h
Supplied equipment: Nitrogen generator GN-8
Concentration: 99.9%
Capacity: 230 m3/h
Supplied equipment: Nitrogen generator GN-9
Concentration: 99%
Capacity: 300 m3/h
Supplied equipment: Nitrogen station GN-33
Concentration: 99,5%
Capacity: 1230 m3/h
Supplied equipment: Nitrogen station GNS-70
Concentration: 99,99%
Capacity: 970 m3/h
All generator models can be mounted on a single frame for quick installation in any heated room. In this case, the equipment is in full technical readiness for start-up.
We produce oxygen and pure nitrogen generators in containerized versions, based on 20 or 40-foot shipping containers, in any climatic design - both for tropical climates and for the far north.
Any generators can be mounted in a special container with autonomous power supply systems (diesel or gas generator) and installed on a chassis for any vehicle or trailer.
